Steering Spindle Kit Fits Ford/New Holland Replaces 82850819

Description

One New Aftermarket Steering Spindle Kit

Tech Info:
-(1) Right Hand Spindle
-Tech Info:
-Right side as sitting in the tractor seat
-10.750″ machined upright shaft
-1.250″ shaft outside diameter
-1.187″ inner bearing diameter
-0.750″ outer bearing diameter
-Machined for 1/4″ x 7/8″ key
-Replaces Part Numbers: F3NN3105AA, 8N3105
–
-(1) Left Hand Spindle
-Tech Info:
-Keyed
-Side
-Axle Length 5 1/4″
-Diameter 1 1/4″
-ID 1 3/16″
-OD 3/4″
-Shaft Length 10 11/16″
-Type Left Hand
-Replaces Part Numbers: F3NN3106AA
–
-(4) Front Spindle Bushing
-Tech Info:
-4 used per tractor,
-1.255″ inside diameter,
-1.378″ outside diameter,
-1.498″ long,
-Must be honed or reamed to size when installed
-Replaces Part Numbers: 2N2109, 2N3109, 81717387, 81802940
–
-(2) Thrust Bearing
-Tech Info:
-Bearing Type Spindle Bearing
-Grease Greaseable
-ID 1.350″
-ID Type Round
-OD 2.200″
-Sourced Import
-Width Overall 0.620″
-Replaces Part Number: 957E3123A

Made to Fit Ford/New Holland:
Models: 8N, NAA
Replaces Part Number(s): F3NN3105AA, 8N3105, 82850819, 8N3105B

Models: 2600, 2310, 4600, 4000, 700, 3600, 4600SU, 2910, 601, 701, 2N, NAA, 2610, 901, 8N, 3910, 3610, 2810, 4000SU, 2000, 900, 801, 800, 600, 9N, 4610
Replaces Part Number(s): 957E3123A

Models This Part Fits:

900, Dexta, Jubilee, NAAAdditional Information: (1) Right Hand SpindleTech Info:Right side as sitting in the tractor seat10.750″ machined upright shaft1.250″ shaft outside diameter1.187″ inner bearing diameter0.750″ outer bearing diameterMachined for 1/4″ x 7/8″ keyReplaces Part Numbers: F3NN3105AA, 8N3105(1) Left Hand SpindleTech Info:KeyedSideAxle Length 5 1/4″Diameter 1 1/4″ID 1 3/16″OD 3/4″Shaft Length 10 11/16″Type Left HandReplaces Part Numbers: F3NN3106AA(4) Front Spindle BushingTech Info:4 used per tractor,1.255″ inside diameter,1.378″ outside diameter,1.498″ long,Must be honed or reamed to size when installedReplaces Part Numbers: 2N2109, 2N3109, 81717387, 81802940(2) Thrust BearingTech Info:Bearing Type Spindle BearingGrease GreaseableID 1.350″ID Type RoundOD 2.200″Sourced ImportWidth Overall 0.620″Replaces Part Number: 957E3123A

Reference Numbers:

180345M3, 180345M91, 226402, 2N3109, 8N3105, 8N3105-KIT, 8N3105B, 8N3106B, Red101, Red101-A
